Description
Measurement parameters
| Part Number |
Measuring range |
Accuracy |
Model
|
| 0403-450 |
0-25mm |
0.003mm |
Carbide flat measuring surface |
usually |
| 0413-450 |
0-25mm |
0.003mm |
Carbide ball measuring surface |
usually |
| 0403-650 |
0-25mm |
0.003mm |
Carbide flat measuring surface |
With mounting nut |
| 0413-650 |
0-25mm |
0.003mm |
Carbide ball measuring surface |
With mounting nut |
| 0493-450 |
0-50mm |
0.005mm |
Carbide flat measuring surface |
usually |
| 0483-450 |
0-50mm |
0.005mm |
Carbide ball measuring surface |
usually |
Dimensions (0403-450)
Dimensions (0493-450)
Main dimensions
| Measuring range |
A |
C |
D |
| 0-25mm |
17.5mm |
28.5mm |
Φ6.5mm |
| 0-50mm |
35.5mm |
53mm |
Φ7.5mm |
