Description
Measurement parameters
| Part Number |
Measuring range |
Accuracy |
Resolution |
Model |
| 0903-554 |
0-25mm |
0.003mm |
0.001mm |
Carbide flat measuring surface |
| 0903-654 |
0-25mm |
0.003mm |
0.001mm |
Carbide flat measuring surface |
| 0913-554 |
0-25mm |
0.003mm |
0.001mm |
Carbide ball measuring surface |
| 0913-654 |
0-25mm |
0.003mm |
0.001mm |
Carbide ball measuring surface |
Dimensions
Main dimensions
Part Number
|
A |
D |
L |
| 0903-554 |
0913-554 |
17.5mm |
Φ6.5mm |
144mm |
| 0903-654 |
0913-654 |
20.5mm |
Φ8.0mm |
147mm |
Function
| power button |
√ |
| Absolute and relative measurement mode switch key |
√ |
| Metric and Imperial measurement mode switch key |
√ |
| Display data output key |
√ |
| Absolute measurement initial value setting key |
√ |
| battery model |
CR2032 |
| Automatic power-off |
√ |
| Data output port |
√ |
| Interface cable (optional) |
P1505 |
| Wireless output device for measurement data (optional) |
1805 |
