Description
Measurement parameters
Part Number | Measuring range | Accuracy |
---|---|---|
104-13-550 | 300-400mm | 0.011mm |
104-14-550 | 400-500mm | 0.013mm |
104-15-550 | 500-600mm | 0.015mm |
104-16-550 | 600-700mm | 0.016mm |
104-17-550 | 700-800mm | 0.018mm |
104-18-550 | 800-900mm | 0.020mm |
104-19-550 | 900-1000mm | 0.020mm |
Dimensions
Main dimensions:
Measuring range | A | L |
---|---|---|
300-400mm | 224mm | 414mm |
400-500mm | 275mm | 514mm |
500-600mm | 325mm | 614mm |
600-700mm | 375mm | 714mm |
700-800mm | 430mm | 814mm |
800-900mm | 480mm | 914mm |
900-1000mm | 530mm | 1014mm |
