Description
Measurement parameters
| Part Number |
Accuracy |
Measuring range |
Resolution |
| With interface |
Without interface |
|
|
|
| 133-01-450 |
133-01-454 |
±0.002mm |
0-25mm |
0.001mm |
| 133-02-450 |
133-02-454 |
±0.002mm |
25-50mm |
0.001mm |
| 133-03-450 |
133-03-454 |
±0.003mm |
50-75mm |
0.001mm |
| 133-04-450 |
133-04-454 |
±0.003mm |
75-100mm |
0.001mm |
| 133-05-450 |
133-05-454 |
±0.003mm |
100-125mm |
0.001mm |
| 133-06-450 |
133-06-454 |
±0.003mm |
125-150mm |
0.001mm |
| 133-07-450 |
133-07-454 |
±0.004mm |
150-175mm |
0.001mm |
| 133-08-450 |
133-08-454 |
±0.004mm |
175-200mm |
0.001mm |
| 133-09-450 |
133-09-454 |
±0.004mm |
200-225mm |
0.001mm |
| 133-10-450 |
133-10-454 |
±0.004mm |
225-250mm |
0.001mm |
| 133-11-450 |
133-11-454 |
±0.005mm |
250-275mm |
0.001mm |
| 133-12-450 |
133-12-454 |
±0.005mm |
275-300mm |
0.001mm |
Dimensions
Main dimensions
| Measuring range |
C |
L |
B |
D |
| 0-25mm |
25mm |
34.5mm |
6mm |
3.0mm |
| 25-50mm |
32.0mm |
59.5mm |
8mm |
3.0mm |
| 50-75mm |
44.5mm |
84.5mm |
8mm |
3.0mm |
| 75-100mm |
57.0mm |
109.5mm |
8mm |
3.0mm |
| 100-125mm |
70.0mm |
135.0mm |
10mm |
3.0mm |
| 125-150mm |
82.0mm |
160.5mm |
10mm |
3.0mm |
| 150-175mm |
94.5mm |
186.0mm |
12mm |
5.5mm |
| 175-200mm |
107.0mm |
211.5mm |
12mm |
5.5mm |
| 200-225mm |
129.5mm |
236.0mm |
23mm |
5.5mm |
| 225-250mm |
142.5mm |
261.5mm |
23mm |
5.5mm |
| 250-275mm |
155.0mm |
287.0mm |
23mm |
5.5mm |
| 275-300mm |
167.5mm |
312.5mm |
23mm |
5.5mm |
