Description
Main dimensions
| Measuring range |
L |
S |
H |
Probe
|
|
|
|
|
A(R) |
B(D) |
| Stroke 10mm |
| 0-10mm |
40mm |
3 mm |
8mm |
0.5mm |
Φ1.5mm |
| 10-20mm |
40mm |
3 mm |
8mm |
0.5mm |
Φ1.5mm |
| 20-30mm |
40mm |
3 mm |
8mm |
0.5mm |
Φ1.5mm |
| 30-40mm |
40mm |
3 mm |
8mm |
0.5mm |
Φ1.5mm |
| 40-50mm |
40mm |
3 mm |
8mm |
0.5mm |
Φ1.5mm |
| Stroke: 20mm |
| 0-20mm |
80mm |
6.5mm |
25mm |
0.75mm |
Φ1.5mm |
| 10-30mm |
80mm |
6.5mm |
25mm |
0.75mm |
Φ1.5mm |
| 20-40mm |
80mm |
6.5mm |
25mm |
0.75mm |
Φ1.5mm |
| 30-50mm |
80mm |
6.5mm |
25mm |
0.75mm |
Φ1.5mm |
| 40-60mm |
80mm |
6.5mm |
25mm |
0.75mm |
Φ1.5mm |
Measure the root diameter of the keyway
