Description
512-01-220
Measurement parameters
| Part Number | Measuring range | Resolution | Measuring depth | Number of probes | Scale (optional) |
|---|---|---|---|---|---|
| 512-01-200 | 18-35mm | 150mm | 9 | User-configured scale | |
| 512-02-200 | 35-60mm | 150mm | 6 | ||
| 512-03-200 | 50-100mm | 150mm | 11 | ||
| 512-04-200 | 50-160mm | 150mm | 12+50mm extension rod | ||
| 512-05-200 | 100-160mm | 150mm | 12 | ||
| 512-06-200 | 160-250mm | 250mm | 5+50mm extension bar | ||
| 512-07-200 | 250-450mm | 250mm | 5+50mm extension bar+100mm extension bar | ||
| 512-01-220 | 18-35mm | 0.01mm | 125mm | 7 | Mechanical dial indicator |
| 512-02-220 | 35-50mm | 0.01mm | 150mm | 3 | |
| 512-03-220 | 50-100mm | 0.01mm | 150mm | 5 | |
| 512-04-220 | 50-160mm | 0.01mm | 150mm | 5+60mm extension rod | |
| 512-05-220 | 100-160mm | 0.01mm | 200mm | 4+80mm extension rod | |
| 512-06-220 | 160-250mm | 0.01mm | 250mm | 5 | |
| 512-07-220 | 250-450mm | 0.01mm | 250mm | 5+100mm extension bar |
512-01-220
512-04-220
