Description
Scale
Measurement parameters
| Part Number | Measuring range | Resolution | Measuring range/week | Accuracy |
|---|---|---|---|---|
| 557-01-090 | 0-3mm | 0.01mm | 1mm | 0.012mm |
| 557-03-090 | 0-5mm | 0.01mm | 1mm | 0.012mm |
| 557-04-090 | 0-10mm | 0.01mm | 1mm | 0.014mm |
Dimensions
Main dimensions
| Part Number | H | A | L |
|---|---|---|---|
| 557-01-090 | 70mm | 10mm | 11.5mm |
| 557-03-090 | 72mm | 12mm | 14mm |
| 557-04-090 | 111mm | 18mm | 11.5mm |
